Light Controlled Relay with Desplay


Light Controlled Relay with Desplay
Images/32962-large.jpg Images/360-3D.jpg   California Proposition 65 Warning
Stock Number: 32962 MP
  Be the first to review this item
$9.95
$4.95
This item is discontinued & is not being restocked.

Did we sell out of a part you need?
You may be able to purchase it directly from our overseas supplier.

 Please note the following restrictions:
   •   $50 minimum per line item
   •   $100 minimum per order

 To inquire, contact:

 Supplier: Aqua Jiang
Email: aquajiang1@outlook.com

 When emailing, please use “MPJA Customer” as the subject line and include the MPJA stock number and quantity needed. The supplier will respond with pricing, lead time and shipping costs.

SHARE

     Email this to a friend

Detailed Description

Compact, microprocessor based, digital light controlled relay with isolated relay outputs.
Features:
Separate Control & Relay boards
Adjustable High & Low light Alarms
Adjustable Hysteresis
Programmable Set Point
Power OFF Memory No need to re-enter settings
CdS Photocell
Display: 3 Digit 0.56" Red LED
LEDs: 1 Red on each board to indicate relay energized
2 Operating Modes: Energize on "Low Light" or "High Light"
Specifications:
Power: 12VAC/DC
Quiescent: <20mA
Relay energized: <50mA
Range: 0-998 LUX
Resolution: 1LUX
Accuracy: 1LUX
Refresh Rate: 0.5sec.
Sensor: CdS Photoresistor (30mm leads with mini connector)
Operating Temp. Range: -10 to 60deg. C; 20-85% humidity
Control Output:
Relay: SPDT
Rated: 10A@250/125VAC 10A/30VDC
Terminal Strips for Relay contacts.
10” Board interconnect cable/mini connectors
5” Power leads/Mini connector
Control Board
W: 2-13/16” H: 1” D: 7/8”
Relay Board
W: 1-13/16” H: 1-1/8” D: 7/8” Ship WT: .08
