Arduino Grove Break-out Board
The Base shield board simplifies connection in the Grove environment. Arduino pins are brought to 4 Pin JST sockets. Each JST provides 2 Signal Pins, A Ground Pin & a =Vcc. You have 4 available I2C connectors, 4 Analog connectors, 7 Digital connectors and 1 UART connector.
The UART connector comprises Arduino’s Digital0 & Digital1 while D2 -D8 Port duplicates ports in a staggered manner: D2=Digital2 & Digital3/D3= Digital3 & Digital4/.../D8=Digital8 & Digital9. The Analog Pins are treated the same A0=Analog 0 & Analog`1/ A1=Analog1 & Analog2 etc. The SPI Header is feed through only as there are no Grove modules that use it. Standardized and stackable shield board compatible with the Arduino I/O Pins.
L: 2-11/16” W: 5/8” WT: .1
