DC Multifunction LCD Panel Meter


DC Multifunction LCD Panel Meter
Stock Number: 36139 ME
  Be the first to review this item
$12.95


Availibilty: In Stock   Units: 9
Quantity



SHARE

     Email this to a friend

Detailed Description


View PDF Data Sheet
DATA SHEET


Snap-in multifunction DC LCD Meter designed to measure the voltage and current, and display it in real-time. Other uses include monitoring, charge and discharge time, charge/discharge capacity, overcharge/discharge control.
Dual 4 digit Backlit LCD Display
Input Voltage: DC 5 V-38 V
Input current: .03A-5A (Meter Operating current: <= 30mA)
Accuracy:
Voltage: 1% + 1 LSD
Current: 1% + 1 LSD
Operating Temperature: -15 C ~ 50 C
Undervoltage( LVP): Adj. 4.8-38VDC, (default 4.8 V)
Overvoltage (OVP): Adj. 4.8-38VDC, (default 38 V )
Overcurrent (OCP): Adj. 0.5A-5.5A range (default 5.5A)
Over Power Ahu (OPP): Adj. 1W-200W (default: 200W)
Overtemperature (OTP): Adj. 40-80 C (default 80 C)
Over Discharge Time (OHP): Adj. 00:01-99.99min (default 00
Cutout: 75mm x 39mm
W: 3-1/16" (79mm) H: 1-11/16" (42mm) D: 1-1/16" (26mm)
WT: .1
