Adjustable Step up (Boost) DC/DC Converter using the XL6009 IC. Ideal Point-of-Use switching Regulator board.
Input/Output Differential should be kept around 2Vmin to 8max
Rated Current: 5A Max See Charts L: 2-13/16" W: 1-7/8" H: 3/4” WT: .09
